Save ggplot Objects to an Editable PowerPoint Presentation

Writes one ggplot per slide into a PowerPoint file using officer::ph_with() and rvg::dml() so that every plot lands as an editable DrawingML vector graphic — shapes, lines, and text remain selectable in PowerPoint. Plots are placed via officer::ph_location() for pixel-exact positioning; titles go into the designated title placeholder via officer::ph_location_type().

Usage

save_ppt(
  object,
  template = "../graphs/RD.pptx",
  powerpoint = "../graphs/pptExample.pptx",
  slide_titles = "Plot",
  layout = "Title and Content",
  master = NULL,
  width = 10.1,
  height = 5.8,
  left = 0,
  top = 1.2,
  panel_box = list(width = 8.88, height = 4.51, left = 2.58, top = 1.63)
)

Arguments

object: A single ggplot object or a named/unnamed list of ggplot objects. Each element produces one slide. May also be an hv_consort object produced by hv_consort().
template: Path to an existing .pptx file used as the slide template. Default "../graphs/RD.pptx".
powerpoint: Output path for the new .pptx file. Default "../graphs/pptExample.pptx".
slide_titles: A character vector of slide titles. Recycled to the number of plots: supply one string for all slides, or one per plot. Default "Plot".
layout: PowerPoint slide layout name from the template. Default "Title and Content".
master: PowerPoint master name from the template, or NULL to use the template's first available master. Default NULL.
width: Plot width in inches within the slide. Default 10.1. Ignored when panel_box is supplied. Ignored for hv_consort objects, whose dimensions are taken from the object's metadata (set at hv_consort() time).
height: Plot height in inches within the slide. Default 5.8. Ignored when panel_box is supplied. Ignored for hv_consort objects, whose dimensions are taken from the object's metadata (set at hv_consort() time).
left: Distance in inches from the left edge of the slide. Default 0.0. Ignored when panel_box is supplied.
top: Distance in inches from the top of the slide. Default 1.2 (below a standard title bar). Ignored when panel_box is supplied.
panel_box: Named list list(width, height, left, top) describing the panel content area to anchor on every slide (in inches). Per-plot slide placement is computed via hv_ph_location() so the panel lands at the same slide coordinates on every slide regardless of axis-label width. Defaults to list(width = 8.88, height = 4.51, left = 2.58, top = 1.63) — the standard CORR fixed-panel rectangle for AATS-style dark decks. Pass panel_box = NULL to fall back to the fixed width/height/left/ top arguments for every slide (legacy behavior). Ignored for hv_consort objects, which are always placed using their own metadata dimensions.

Value

Invisibly returns the path given by powerpoint.

Details

The package ships a small dark-background test template derived from the canonical CORR deck (master, layouts, theme; no content slides). Use it to try save_ppt() without hunting for a template:

template <- system.file("extdata", "hv_ppt_template.pptx",
                        package = "hvtiPlotR")

Examples

if (FALSE) { # \dontrun{
library(ggplot2)

# ----------------------------------------------------------------------
# Recommended workflow: preview with light, save with dark
# ----------------------------------------------------------------------
# Build the plot with theme_hv_ppt_light() so it renders crisply in the
# RStudio viewer (black text/border on the IDE's white background) while
# you iterate on scales and labels:
p_preview <- ggplot(mtcars, aes(x = wt, y = mpg)) +
  geom_point() +
  labs(x = "Weight", y = "Miles per gallon", title = "Fuel economy") +
  theme_hv_ppt_light()
print(p_preview)            # interactive check

# When the layout looks right, swap to theme_hv_ppt_dark() for the deck
# (white text + black panel against a dark slide template) and save:
p_slide <- p_preview + theme_hv_ppt_dark()
save_ppt(
  object       = p_slide,
  template     = "graphs/RD.pptx",
  powerpoint   = "graphs/fuel_economy.pptx",
  slide_titles = "Fuel Economy by Weight"
)

# List of plots — one slide per plot, individual titles
p2 <- ggplot(mtcars, aes(x = factor(cyl), y = mpg)) +
  geom_boxplot() +
  labs(x = "Cylinders", y = "Miles per gallon") +
  theme_hv_ppt_dark()

save_ppt(
  object       = list(p_slide, p2),
  template     = "graphs/RD.pptx",
  powerpoint   = "graphs/deck.pptx",
  slide_titles = c("Scatter: fuel economy", "Box: mpg by cylinder count")
)

# No y-axis label — let the slide title carry the meaning. `y = NULL`
# drops the axis title; the numeric tick labels remain.
p_noy <- ggplot(mtcars, aes(x = factor(cyl), y = mpg)) +
  geom_boxplot() +
  labs(x = "Cylinders", y = NULL) +
  theme_hv_ppt_dark()

save_ppt(
  object       = p_noy,
  template     = "graphs/RD.pptx",
  powerpoint   = "graphs/mpg_by_cyl.pptx",
  slide_titles = "Miles per Gallon by Cylinder Count"
)

# Manuscript (white background) for AATS-style presentations
pm <- ggplot(mtcars, aes(x = wt, y = mpg)) +
  geom_point() +
  labs(x = "Weight", y = "Miles per gallon") +
  theme_hv_manuscript()

save_ppt(
  object       = pm,
  template     = "graphs/RD-white.pptx",
  powerpoint   = "graphs/manuscript.pptx",
  slide_titles = "Fuel Economy"
)

# ----------------------------------------------------------------------
# panel_box: anchor the plot panel to a fixed rectangle on every slide
# ----------------------------------------------------------------------
#
# Problem: when plots in a deck have different y-axis ranges
# (e.g. "1.0" vs "4567.2"), axis-label widths differ and shift the
# panel inside a fixed ph_location(). Without a panel_box the plot
# panel drifts between slides — visually jarring against the slide
# background.
#
# Solution: pass `panel_box = list(width = ..., height = ..., left = ...,
# top = ...)`. This describes the PANEL CONTENT AREA itself — the
# rectangle bounded by the axis lines, not the outer plot extent.
# save_ppt() calls [hv_ph_location()] for each plot, measures the
# axis / title / legend chrome around the panel, and adjusts per-slide
# placement so the panel lands at the target rectangle on every slide.
# The plot's OUTER dimensions therefore vary per slide (chrome floats
# around a constant panel), analogous to how [hv_ggsave_dims()] drives
# ggsave's width/height from a target panel size.
#
# Workflow: build plots with `theme_hv_ppt_light()` so the white panel
# + black border renders crisply in the IDE viewer during development.
# At save time, the PowerPoint template controls the SLIDE background
# (e.g. blue gradient), so a light_ppt plot on a dark slide template
# produces AATS-style white-panel-on-dark-slide decks.

p_small <- ggplot(mtcars, aes(hp, mpg)) +
  geom_point() +
  scale_x_continuous(breaks = seq(0, 400, 100), expand = c(0, 0)) +
  scale_y_continuous(labels = function(x) sprintf("%3.1f", x)) +
  labs(x = "Horsepower", y = "MPG") +
  theme_hv_ppt_light()

p_big <- ggplot(mtcars, aes(hp, mpg)) +
  geom_point() +
  scale_x_continuous(breaks = seq(0, 400, 100), expand = c(0, 0)) +
  scale_y_continuous(labels = function(x) sprintf("%8.1f", x * 10000)) +
  labs(x = "Horsepower", y = "MPG (x10k)") +
  theme_hv_ppt_light()

# Preview each plot interactively (e.g. print(p_small) in RStudio) to
# check decoration before saving.

# Without panel_box: panel drifts between slides because the big-number
# labels eat more horizontal space than the small-number labels.
save_ppt(
  object       = list(p_small, p_big),
  template     = "graphs/RD-dark.pptx",
  powerpoint   = "graphs/drifting_deck.pptx",
  slide_titles = c("Small y-axis", "Big y-axis")
)

# With panel_box: target is an 8.88" x 4.51" panel at slide coordinates
# (2.58", 1.63"). The panel content area lands at exactly that rectangle
# on both slides; axis labels extend outside it as each plot requires.
# The 2.58" left margin leaves room for a wide "99999.9"-style y-axis
# label on dark PPT templates rendered at base_size = 32.
save_ppt(
  object       = list(p_small, p_big),
  template     = "graphs/RD-dark.pptx",
  powerpoint   = "graphs/anchored_deck.pptx",
  slide_titles = c("Small y-axis", "Big y-axis"),
  panel_box    = list(width = 8.88, height = 4.51, left = 2.58, top = 1.63)
)

# Sizing advice: panel_left and panel_top must be large enough for the
# widest axis labels in the deck. If chrome extends past the left or top
# slide edge, hv_ph_location() emits a warning naming that edge.
} # }
