Prepare survival difference (life-gained) data for plotting

Stores pre-computed survival difference data as an hv_survival_difference object. Pass the result to plot.hv_survival_difference() to render the plot. Covers tp.hp.dead.life-gained.sas and the survival-difference component of tp.hp.numtreat.survdiff.matched.sas.

Usage

hv_survival_difference(
  diff_data,
  x_col = "time",
  estimate_col = "difference",
  lower_col = NULL,
  upper_col = NULL,
  group_col = NULL
)

Arguments

diff_data

Data frame of pre-computed survival differences. See sample_survival_difference_data().

x_col

Name of the time column. Default "time".

estimate_col

Name of the difference column. Default "difference".

lower_col

Lower CI column, or NULL. Default NULL.

upper_col

Upper CI column, or NULL. Default NULL.

group_col

Grouping column for multiple comparisons, or NULL. Default NULL.

Value

An S3 object of class c("hv_survival_difference", "hv_data").

See also

plot.hv_survival_difference(), sample_survival_difference_data(), hv_nnt()

Examples

library(ggplot2)

diff_dat <- sample_survival_difference_data(
  groups = c("Control" = 1.0, "Treatment" = 0.70)
)

sd <- hv_survival_difference(diff_dat,
  lower_col = "diff_lower", upper_col = "diff_upper"
)
plot(sd) +
  geom_hline(yintercept = 0, linetype = "dashed", colour = "grey50") +
  scale_x_continuous(limits = c(0, 10), breaks = 0:10) +
  scale_y_continuous(limits = c(-5, 30),
                     labels = function(x) paste0(x, "%")) +
  labs(x = "Years", y = "Survival Difference (%)") +
  hv_theme("poster")
